Working principle:
The equipment uses water electrolysis to generate pure hydrogen and pure oxygen. By controlling the liquid level of hydrogen / oxygen tank, to ensure the hydrogen purity. It will go through the processes such as hydrogen washing, gas/liquid separation, cooling, purifying deoxidization and dry process to produce high purity hydrogen.
Working conditions:
1. This equipment cannot be used in the open air, and it should has protection measures against rain, lightning and rodents.
2. Good ventilation must be ensured in the place where the equipment is installed and used, and there should be a ventilation device at the top of the place where the equipment is placed to ensure that gas will not accumulate.
3. The on-site ambient temperature is guaranteed to be above 0°C and below 40°C.
Structure feature:
1. Electrolytic tank: applying brand-new structure design, low inner-electrode voltage, high current density, and low energy consumption per unit of hydrogen production.
2. Gas/liquid separator: simplifying the previous product structure, which makes the space smaller and better effects of gas/liquid separation.
3. Explosion-proof requirements: all the parts are designed as explosion-proof. Clients can choose the appointed brand parts if they require.
4. Cabinet: one integrated cabinet or split-type, even containerized type for client’s convenient use.
5. Pipes: all pipes are made of SS304 stainless steel and connected in the form of live joints, which changes the disadvantages of traditional flanges that are cumbersome and bulky, decreasing the user's maintenance cost and making the equipment space more reasonable, reducing the floor space.
6. Purifier and dryer:
Ⅰ. It is the first in China to use four-way valve to replace more than a dozen valves with a very high failure rate for tower inversion work.
Ⅱ. The condensed water in the system can be automatically released without any independent control.
III. The purity of hydrogen outlet reaches to 99.999% and the dew point is down to -70℃.
Note: Model below CHG-50, the equipment can be designed as one integrated cabinet structure. Model above CHG-50, the electrolytic tank needs to be placed separately and the gas/liquid separator can be designed as one integrated cabinet structure.
型号 MODEL | 最大氢气产量 (Nm³/ h) H2 CAPACITY | 最大氧气产量 (Nm³/ h) O2 CAPACITY | 氢气纯度 H2 PURITY | 氧气纯度 O2 PURITY | 直流电流 (A) CURRENT | 直流电压 (V)DC VOLTAGE | 电解槽工作温度 CELL WORKING TEMPERATURE | 总耗水量 TOTAL WATER CONSUMPTION | 冷却水用量 COOLING WATER CONSUMPTION | 使用压力 PRESSURE ACCORDING TO NEEDS |
CHG-1 | 1 | 0.5 | 99.999% | 99.3% | 250 | 22 | ≤85℃ | 1L/h | 0.2m³/ h |
≤0.6MPa
≤1.6MPa
≤3.2MPa
|
CHG-5 | 5 | 2.5 | 99.999% | 99.3% | 250 | 105 | ≤85℃ | 5L/h | 1.0m³/ h |
CHG-10 | 10 | 5 | 99.999% | 99.3% | 1000 | 54 | ≤85℃ | 10L/h | 2.0m³/ h |
CHG-15 | 15 | 7.5 | 99.999% | 99.3% | 1000 | 80 | ≤85℃ | 15L/h | 3.0m³/ h |
CHG-20 | 20 | 10 | 99.999% | 99.3% | 1000 | 105 | ≤85℃ | 20L/h | 4.0m³/ h |
CHG-30 | 30 | 15 | 99.999% | 99.3% | 1000 | 158 | ≤85℃ | 30L/h | 6.0m³/ h |
CHG-50 | 50 | 25 | 99.999% | 99.3% | 1000 | 265 | ≤85℃ | 50L/h | 10m³/ h |
CHG-75 | 75 | 37.5 | 99.999% | 99.3% | 1000 | 394 | ≤85℃ | 75L/h | 15m³/ h |
CHG-100 | 100 | 50 | 99.999% | 99.3% | 3000 | 176 | ≤85℃ | 100L/h | 20m³/ h |
CHG-150 | 150 | 75 | 99.999% | 99.3% | 3000 | 264 | ≤85℃ | 150L/n | 30m³/ h |
CHG-200 | 200 | 100 | 99.999% | 99.3% | 3000 | 325 | ≤85℃ | 200L/h | 40m³/ h |
CHG-250 | 250 | 125 | 99.999% | 99.3% | 3000 | 438 | ≤85℃ | 250L/h | 50m³/ h |
CHG-300 | 300 | 150 | 99.999% | 99.3% | 3000 | 528 | ≤85℃ | 300L/h | 60m³/ h |
cHG-350 | 350 | 175 | 99.999% | 99.3% | 3000 | 612 | ≤85℃ | 350L/h | 70m³/ h |
CHG-400 | 400 | 200 | 99.999% | 99.3% | 3000 | 700 | ≤85℃ | 400L/h | 80m³/ h |
CHG-500 | 500 | 250 | 99.999% | 99.3% | 8050 | 328 | ≤85℃ | 500L/h | 100m³/ h |
CHG-600 | 600 | 300 | 99.999% | 99.3% | 8050 | 390 | ≤85℃ | 600L/h | 120m³/ h |
CHG-700 | 700 | 350 | 99.999% | 99.3% | 8050 | 457 | ≤85℃ | 700L/h | 140m³/ h |
CHG-800 | 800 | 400 | 99.999% | 99.3% | 8050 | 524 | ≤85℃ | 800L/n | 160m³/ h |
CHG-900 | 900 | 450 | 99.999% | 99.3% | 8050 | 588 | ≤85℃ | 900L/h | 180m³/ h |
CHG-1000 | 1000 | 500 | 99.999% | 99.3% | 8050 | 653 | ≤85℃ | 1000L/h | 200m³/ h |
